Residential Energy Storage System

ceshi

Modulc capacity(Ah) 100
Cell model/Configuration 3.2V00Ah/64S1P 3.2V00Ah/80SIP 3.2V00Ah/96SIP 3.2V100Ah/112SIP 3.2V100Ah/128SIP 3.2V00Ah/144SIP 3.2V00Ah/160SIP
System nominal voltago(V) 204.8  256  307.2  358.4  409.6  460.8  512
System operating voltage(V) 185.6~227.2 232~284 278.4~340.8 324.8~397.6 371.2~454.4 417.6~511.2 464~568
System energy(kWh) 20.48  25.6  30.72  35.84  40.96  46.08  51.2
Charge/ Discharge Current(A) Rccommend 50
Max 100
Working temperaturo Charge:0℃~50℃;DisCharge:-20℃~55℃
Communication port CAN2.0/RS485/WIFI
Humidity 5~85%RH Humidity
Altitudo ≤2000 m
IP rating of cnclosurc IP20
Dimension W*D*H(mm) 538*492*791 538*492*941 538*492*1091 538*492*1241 538*492*1391 538*492*541 538*492*1691
Weight approximate(kg) 195  240  285  330  375  420  465
Installation locationStorage Rack Mounting
Storage temperature(℃) 0℃~35℃
Recommend depth of discharge 90%
Cycle life 25±2℃,0.5C/0.5C,EOL70%≥6000



Modulc capacity(Ah) 100
Cell model/Configuration 3.2V00Ah/64S1P 3.2V00Ah/80SIP 3.2V00Ah/96SIP 3.2V100Ah/112SIP 3.2V100Ah/128SIP 3.2V00Ah/144SIP 3.2V00Ah/160SIP
System nominal voltago(V) 204.8  256  307.2  358.4  409.6  460.8  512
System operating voltage(V) 185.6~227.2 232~284 278.4~340.8 324.8~397.6 371.2~454.4 417.6~511.2 464~568
System energy(kWh) 20.48  25.6  30.72  35.84  40.96  46.08  51.2
Charge/ Discharge Current(A) Rccommend 50
Max 100
Working temperaturo Charge:0℃~50℃;DisCharge:-20℃~55℃
Communication port CAN2.0/RS485/WIFI
Humidity 5~85%RH Humidity
Altitudo ≤2000 m
IP rating of cnclosurc IP20
Dimension W*D*H(mm) 538*492*791 538*492*941 538*492*1091 538*492*1241 538*492*1391 538*492*541 538*492*1691
Weight approximate(kg) 195  240  285  330  375  420  465
Installation locationStorage Rack Mounting
Storage temperature(℃) 0℃~35℃
Recommend depth of discharge 90%
Cycle life 25±2℃,0.5C/0.5C,EOL70%≥6000
